The importance of using high-quality RF cables cannot be overstated. Inferior cables can lead to signal loss, poor transmission quality, and increased susceptibility to interference. Therefore, selecting and using properly rated and shielded RF cables is essential for maintaining the integrity of the transmitted signals.
